Garrett G Series G45-1600 Turbocharger

by Garrett
SKU 888169-5006S - 757707-0019
Save 25% Save 25%
Original price $7,305.50
Original price $7,305.50 - Original price $7,796.50
Original price $7,305.50
Current price $5,479.15
$5,479.15 - $5,847.00
Current price $5,479.15

 Series turbochargers feature the latest innovations in turbocharger technology. Advanced compressor and turbine aero provide a wide range of performance boosting solutions for 2.0L - 8.0L engine platforms. Offered in standard rotation, with four compressor inducer options and a variety of V-Band and T4 twin scroll inlet turbine housing configurations making it easy to select the right turbocharger for your application.

• G45-1600 compressor aero increases flow up to 16% (compared to GTX4508R 80mm)
• 80mm compressor inducer | 109mm compressor exducer
• Dual ceramic ball bearing with steel cages
• G Series turbine aero increases flow 14% (compared to GTX45R)
• Inconel turbine wheel with 89mm inducer flows up to 56 lbs/min
• Lightweight aluminum backplate
• Fully machined speed sensor and pressure ports
• Water fittings included with supercore
• Stainless steel turbine housings available in T4 divided inlet
• Sized for drag racing classes: Sport Front Wheel Drive, Ultimate Street, Super Street, Street Fighter
