PRP V2 Race Series Plus Crank Ignition Timing Kit - Nissan RB20/RB25/RB26/RB30

The PRP V2 Race Series Plus Crank Ignition Timing Kit is the crankshaft half of our V2 Race Series Plus ignition timing system, to suit Nissan RB20, RB25, RB26 and RB30 engines. The crank gear and 12 tooth timing wheel are machined in house from one piece of billet into a monoblock assembly, eliminating failure points and delivering extremely accurate ignition and mechanical timing.

Running both a cam and crank sensor protects the engine against timing belt deflection. RB timing belts have been known to stretch up to 8mm, and a fluctuation of just a few degrees can be the difference between extra power and a damaged engine. Pair this kit with the V2 Race Series Plus Cam Ignition Timing Kit (or any PRP cam kit / mechanical fuel pump kit) to give your ECU a true picture of what both the crank and cams are doing.

Key Features

• 1-piece billet monoblock crank gear and 12 tooth timing wheel, zero failure points
• ZF (Cherry) Hall Effect sensor, resistant to electrical noise and interference
• Wide tooth profile for minimal risk of tooth miscount; sensor gap is less critical than reluctor type kits
• Includes PRP rear EN36 blackened/hardened washer (Plus upgrade)
• Swept-back crank sensor mount clears all common balancers, including ATI, OEM, Fluid Damper and Ross
• 12 tooth configuration suits most aftermarket ECUs
• Recommended for applications up to 1000whp

Kit Contains

• 1-piece billet 12 tooth crank timing wheel and crank gear (monoblock assembly)
• PRP rear EN36 blackened/hardened washer
• ZF (Cherry) Hall Effect crankshaft sensor (red)
• Swept-back bottom sensor mount (black)
• Teflon shielded twin-core wire and braided sheath
• Deutsch connector set, pins, gauze and heat shrink
• Custom injection moulded 90 degree silicone boot
• Bolts and general hardware

Notes

• This is the crank kit only. Cam kit sold separately (V2 Race Series Plus Cam Ignition Timing Kit).
• Crank sensor brackets are only available in black.
• The Race Series crank sensor is installed on an angle by design. It is not cross threaded.
