Street and Race Turbocharger - Next Gen PT122
The most powerful single turbo setup on the planet is about to get even more aggressive. Our record-breaking 118 GEN2 Large Frame turbocharger is being replaced by the all-new NEXT GEN 122mm Large Frame turbocharger.
Bringing the latest advancements from our NEXT GEN turbo lineup, this redesigned turbocharger features an all-new compressor wheel and enhanced compressor cover, taking your single turbo build to the next level.
Key Features:
- Exclusive NEXTGEN CEA® (Competition Engineered Aerodynamics) 122mm compressor
- Large frame compressor cover with a smooth, 7" radiused inlet
- Air-cooled, dual ceramic ball-bearing CHRA for maximum durability and response
High-flow, highly efficient 114mm CEA turbine wheel
Recommended Accessories (Sold Separately):
- Oil Feed Fitting: PFT047-3047
- Oil Drain Flange: PTP074-2102 / PTP074-2104
- Turbine Housing Inlet Flange: PTP074-1014
- Turbine Housing Outlet Flange: PTP074-3029 / PTP074-3030
- Turbine Housing Outlet Clamp: PTP071-1035
- Turbo Speed Sensor: PEL015-9500
- CCP Comp Cover Safety Blanket: THR-05
- T5/T6 Turbine Inlet Gasket: PTP075-5009
Specifications:
- Compressor Wheel Inducer: 121.92mm
- Compressor Wheel Exducer: 152.40mm
- Turbine Wheel Inducer: 130.56mm
- Turbine Wheel Exducer: 114.30mm
- Max Shaft Speed: 94,153 RPM
- Turbine Housing Options: 1.32 & 1.50 A/R T5 Inlet / V-Band Discharge
The evolution of high-performance turbocharging continues with Precision's latest innovation. Get ready to push the limits like never before!
